Old February 19th, 2008, 02:17 PM   #166
Inner Circle

Join Date: Dec 2005
Location: Rhode Island
Posts: 4,048
Thanks Bill for your continued work on the presets. I will be home this weekend after a two week shoot were I used your preset with cine 1 & 4 with success. It will be interesting to view on my larger monitors compared to the 17" Macbook pro.

So far all looks ok but I did change the BLacks to -4 an it seem to help in the high contrast shoots.

Always interested in what you find next.
__________________
Paul Cronin
www.paulcroninstudios.com
Paul Cronin is offline   Reply With Quote
Old February 19th, 2008, 05:47 PM   #167
Trustee

Join Date: Nov 2006
Location: Honolulu, HI
Posts: 1,435
Everyone...

What is the recipe for obtaining maximum tonal RANGE? Something that will work in every situation regardless if it's bright or in low light?

I would like to capture all my images with as much shadow AND highlight detail as possible, without crushed blacks or blown out whites. Something with a smooth and even tonal range from 0-108%.

I guess this would be called the "holy grail preset?"
Warren Kawamoto is offline   Reply With Quote
Old February 19th, 2008, 06:49 PM   #168

Join Date: Nov 2001
Location: santa fe, nm
Posts: 3,264
Images: 10
warren...no such animal. no such thing as a perfect compromise.
latitude in hi contrast scenes is entirely different from latitude in low contrast scenes. anything that works well in low contrast will not work well in hi contrast and visa versa. throw the dice and takes your chance.

Last edited by Bill Ravens; February 19th, 2008 at 07:30 PM.
Bill Ravens is offline   Reply With Quote
Old February 19th, 2008, 07:06 PM   #169
Major Player

Join Date: Sep 2007
Location: Palm Desert, California
Posts: 311
Quote:
Originally Posted by Warren Kawamoto View Post
Everyone...

What is the recipe for obtaining maximum tonal RANGE? Something that will work in every situation regardless if it's bright or in low light?

I would like to capture all my images with as much shadow AND highlight detail as possible, without crushed blacks or blown out whites. Something with a smooth and even tonal range from 0-108%.

I guess this would be called the "holy grail preset?"
You need find a preset (PP) for each of the lighting conditions you shoot under. Generally you will loose a bit at one end but even so the latitude of this camera is amazing.

Here is something you might try that I do. I want the most detail in the blacks as I reasonably can, IE I don't want crushed blacks and CINE4 is a good preset for that but CINE4 is a very "bright" gamma and I shoot under the high hot sun, so I use CINE4 with the (black stretch slightly dropped) and under-expose by about 1.5 stops.

Mike
Michael H. Stevens is offline   Reply With Quote
Old February 19th, 2008, 09:04 PM   #170
Trustee

Join Date: Nov 2006
Location: Honolulu, HI
Posts: 1,435
Thanks Bill & Mike!
Warren Kawamoto is offline   Reply With Quote
Old February 20th, 2008, 05:44 AM   #171
Regular Crew

Join Date: Dec 2007
Location: Viersen, Germany
Posts: 120
@Bill:
I have a problem with your TC2-Preset. I get a greenish looking sky with your preset.

I did a comparison between your TC2 preset (with Black and Blackgamma=0), mine (hisat with Level=5 but no other modifications, Cine4, detail=off, Gamma=0, Black=0, Blackgamma=0) and a HV20 (TV-Mode, Aperture under my control - never thought the HV20 looks so bad compared to the EX1!)

http://rapidshare.com/files/93376520..._HV20.mp4.html


regards Dennis
Dennis Schmitz is offline   Reply With Quote
Old February 20th, 2008, 07:47 AM   #172

Join Date: Nov 2001
Location: santa fe, nm
Posts: 3,264
Images: 10
recheck your matrix values. you didn't set the to the right values I speced.
Bill Ravens is offline   Reply With Quote
Old February 20th, 2008, 08:03 AM   #173
Regular Crew

Join Date: Dec 2007
Location: Viersen, Germany
Posts: 120
Quote:
Originally Posted by Bill Ravens View Post
recheck your matrix values. you didn't set the to the right values I speced.

I used your hisat matrix values (TC2) with other gamma and black gamma settings because the blacks were crushed.

I cannot test with your original gamma and black gamma settings because it's rainy today. ;)


regards Dennis
Dennis Schmitz is offline   Reply With Quote
Old February 20th, 2008, 08:14 AM   #174

Join Date: Nov 2001
Location: santa fe, nm
Posts: 3,264
Images: 10
check again
Bill Ravens is offline   Reply With Quote
Old February 21st, 2008, 04:47 AM   #175
Regular Crew

Join Date: Dec 2007
Location: Viersen, Germany
Posts: 120
@Bill:
These were the settings I've used:

Matrix=High SAT
Phase=-5
R-G=+75
R-B=0
G-R=-18
G-B=-32
B-R=-27
B-G=+13

OffSet White=Off

Detail=Off

Skin Tone Detail=Off

Gamma Level=0
Select=Cine4

Black=0
Black Gamma=0

Low Key Sat=+10



regards Dennis
Dennis Schmitz is offline   Reply With Quote
Old February 21st, 2008, 10:50 AM   #176
Major Player

Join Date: Sep 2007
Location: Palm Desert, California
Posts: 311
Did Bill update his settings? I don't remeber the +10 LowKey Sat and I have Black at -12. Results very nice.
Michael H. Stevens is offline   Reply With Quote
Old February 21st, 2008, 11:32 AM   #177

Join Date: Nov 2001
Location: santa fe, nm
Posts: 3,264
Images: 10
Looks right, except:
Black: -12
Low Key Sat: 0

I have, since, backed off to Black at -8 to givre me a little more headroom in the shadows. I run these all settings with STD1, CINE1, CINE3, CINE4. Each one shifts the exposure latitude, depending on scene illumination.

STD1 gives a pretty contrasty image in the EVF, but, grades very well in post.

Be SURE you white balance.
Bill Ravens is offline   Reply With Quote
Old February 25th, 2008, 03:44 AM   #178
Tourist

Join Date: Feb 2008
Location: New York City, NY
Posts: 3
Picture Profile settings for low light outdoor scenes at night

The settings are perfect for sunny scenes. But what about night scenes outdoors in low light. Is there any way to get rid of the noise? I tried switching to STD 1 and this helped a bit getting rid of the noise but not completely. Is there something else I need to be doing?
Cody
Cody Stanton is offline   Reply With Quote
Old February 25th, 2008, 07:10 AM   #179
Regular Crew

Join Date: Dec 2007
Location: Viersen, Germany
Posts: 120
Hmm, I've checked again, because wheather is great today.

It seems that the picture looks more natural with your preset.
(reddish sky with mine, greenish sky with Bill's TC2 but it looks better)


Edit: why do these pictures look different when viewing in firefox?
My preset seems to produce more natural colors when viewing in firefox - strange...

Edit2: The MXF files look the same in VLC compared to firefox, but very different in windows live photogallery...

regards Dennis
Attached Thumbnails
Picture Profile Recipes-billstc2.jpg   Picture Profile Recipes-mypreset.jpg

Dennis Schmitz is offline   Reply With Quote
Old February 25th, 2008, 08:13 AM   #180
Inner Circle

Join Date: Aug 2006
Location: Poland
Posts: 4,086
OK guys.

After some more testing, I must revise my understanding of what the philosophy behind both CINE gammas and CINE matrix is on this camera. Certainly, it's NOT the same I had on the V1, and thus NOT what I expected. Rather than more punchy/saturated than the STD gammas/ STD matrix, they seem to be muted and washet-out. BUT, given a second thought, do CINEmatic picture (as seen in the movie theaters) look contrasty? Not at all, so perhaps this is the CineAlta philosophy, after all? Low contrast, soft and saturated pictures...

Anyway, the two grabs below show a comparison of the same scenery using:

- Bill Raven's TC (or was it TC2), with Cine1 gamma on the left
- my new PP on the right:

gamma: STD1 level 0
matrix: Hisat level 20, phase 15, all colour pairs at zero (default)
Black: -25
Black gamma: -15
Low Key Sat: 15


As you can see, the STD1-based picture is much brighter and punchy than the CINE1-based one. What's more, this PP's knee (unlike that of CINE1) is not only adjustable (all defaults here), but even with default settings does NOT produce the awful "abrupt highlight clipping" as discussed in another thread, and mentioned by Adam Wilt (just see the extremely back-lit images at the bottom - the left one has been taken with Cine1 and shown in the "abrupt clipping" thread; see what I mean?).

So, the question is: to CINE, or not to CINE? - when one is after this punchy, contrasty and saturated look... Of course, the grabs on the right has been made too contrasty on purpose in order to prove my point; their blacks are too severely compressed for sure!
Attached Thumbnails
Picture Profile Recipes-image68.jpg   Picture Profile Recipes-image67.jpg

Picture Profile Recipes-image70.jpg   Picture Profile Recipes-image69.jpg

__________________
Sony PXW-FS7 | DaVinci Resolve Studio; Magix Vegas Pro; i7-5960X CPU; 64 GB RAM; 2x GTX 1080 8GB GPU; Decklink 4K Extreme 12G; 4x 3TB WD Black in RAID 0; 1TB M.2 NVMe cache drive

Last edited by Piotr Wozniacki; February 25th, 2008 at 09:40 AM.
