XL2 with Nikon Primes!

Martin Catt · September 30th, 2007, 01:10 PM

No. A 50mm lens would give the apparent focal length of 360mm on the XL2 because of the smaller CCD size compared to a 35mm frame. Rule of thumb is to multiply the focal length by 7.2 to get the apparent focal length.

Martin

Tony Davies-Patrick · October 1st, 2007, 05:10 AM

I have used a Canon XL-NIKON Nikkor adapter for years to bayonet my vast range of Nikkors to XL bodies, and would certainly be lost without it.

There are a few different companies making them, in either plastic/hard-resin components or metal. By far the best are made of solid metal.

The one that I have always used is made by Les Bosher - a camera engineer who has been working for film/video/television for around 25-years.

http://www.lesbosher.co.uk/

Les will also make special mounts to fit most other makes of lenses such as Pentax/Minolta/Contax/Zeiss etc.

Daniel Kucharski · October 29th, 2007, 07:50 AM

Quote:

Originally Posted by Paul V Doherty

Just recieved the Novoflex XL-Nikon adaptor from B&H.
It is a very well constructed and engineered piece of solid metal with a nice
Nikon lens release mechanism.
Beautifully finished in either powder coat or anodised aluminium - I don't know which.

Shown in the photos are:

Tokina 28-80mm f2.8 Zoom
Nikon 85mm f1.4
Sigma Fisheye f2.8

A quick test in the backyard proved the combination of 35mm SLR lenses and the XL2 to be a vastly superior image than the stock Canon 20x XL lens.
Even with the 7.2x magnification factor, the image quality is simply so superior and the bonus of full manual control with nice full-throw focus on the barrel is hard to beat.
I would definitely recommend this setup for anyone with a need for full manual control if you can live with the massive focal length magnification.
It sure beats paying $$$$ for the Canon manual lens, and most people have some decent SLR lenses at their disposal.

I mostly shoot concerts, theatre and rock bands, so the 7.2x magnification is actually an advantage when shooting from the back or middle of the auditorium.

I highly recommend the Novoflex adaptor if you have some Nikon lenses lying around!!!!

Could you please send a video made with the adapter to my email because i just about to buy the xl2 just for the adapter. Email:mail@danielk.plus.com

Daniel Kucharski · December 29th, 2007, 06:45 AM

i never really understood does the adapter effect the DOF?

Paul V Doherty · December 31st, 2007, 12:06 AM

Daniel,

I'm on a slow satellite uplink for the next 5 months. I'm afraid I can't upload any videos - sorry :(

But I CAN vouch for a Nikon-XL adaptor - the results are worth a few hundred dollars for a quality steel or brass adaptor. I don't recommend plastic adaptors.

There is no gain in DOF with a Nikon-XL adaptor. You will still get the same DOF at the same focal length as the stock 20x Canon XL lens

Don DesJardin · December 31st, 2007, 04:44 PM

I had an XL1 as my first camera, and it served me well. I have now upgraded to an XL H1, skipping the XL2 step. I purchased an XL to Nikon adapter from RSB Film in the UK, but they no longer carry it as an item. I was using a Nikon 80-400mm, Sigma 400mm APO Macro, and an old Tokina 80-200 with the XL1, and I was very satisfied with the results. With the XL H1, I have used the same lenses with mixed results. The Nikon 80-400mm falls off at about 380mm, the Sigma 400mm is tack sharp, and the Tokina is also very sharp. I am currently using the Tokina 80-200mm as my work horse lens, and I have coupled a Nikon TC14A (1.4x) with it, which gives me an effective ~2000mm. This combo has worked out very well for me, and so far has produced very sharp and crisp video, even after being down converted to standard DV. Attached are a few images that are video frame grabs from a down converted source. All the images were shot using the Tokina 80-200mm coupled with the TC14A, including the macro shot of the fly.

For reasons I don't understand, I have had trouble uploading videos on this site. So, if your interested in seeing videos shot with the Tokina combo, go to this site.

http://surfbirds.com/video2/index.php

Any video with the user name dond, is mine. Most of them are 16:9, but when they are first displayed, they show as squished 4:3, so click the resize button (blue square) in the lower right corner of the viewer to display right aspect ratio.

Michael Sweeney · January 5th, 2008, 03:24 AM

so what is the real point of this adapter? seems that it would work mostly for wildlife videos because of the huge magnification and such. i was very interested at first because i am looking for something such as the redrock m2 to use slr lens.

John Welsh · January 5th, 2008, 06:33 AM

7.2x
someone knows what is the multiplyer on 35mm adapters?

September 30th, 2007, 01:10 PM	#16
Martin Catt Major Player Join Date: Jun 2007 Location: The Colony TX Posts: 327	No. A 50mm lens would give the apparent focal length of 360mm on the XL2 because of the smaller CCD size compared to a 35mm frame. Rule of thumb is to multiply the focal length by 7.2 to get the apparent focal length. Martin __________________ Canon XF300, Canon 5DMkII, Canon XL2, Rolls MX422 mixer, Zoom H4N, AT899 lavs, AT2020's, Azden SGM 1X shotgun, Manfrotto 501 head on 351 tripod

October 1st, 2007, 05:10 AM	#17
Tony Davies-Patrick Trustee Join Date: Feb 2005 Location: Worldwide Posts: 1,589	I have used a Canon XL-NIKON Nikkor adapter for years to bayonet my vast range of Nikkors to XL bodies, and would certainly be lost without it. There are a few different companies making them, in either plastic/hard-resin components or metal. By far the best are made of solid metal. The one that I have always used is made by Les Bosher - a camera engineer who has been working for film/video/television for around 25-years. http://www.lesbosher.co.uk/ Les will also make special mounts to fit most other makes of lenses such as Pentax/Minolta/Contax/Zeiss etc. __________________ www.WILDCARP.com www.NIKON.me.uk

December 29th, 2007, 06:45 AM	#19
Daniel Kucharski Tourist Join Date: Oct 2007 Location: London Posts: 4	hi i never really understood does the adapter effect the DOF?

December 31st, 2007, 04:44 PM	#21
Don DesJardin Major Player Join Date: Jan 2004 Location: Ventura, California, USA Posts: 255	I had an XL1 as my first camera, and it served me well. I have now upgraded to an XL H1, skipping the XL2 step. I purchased an XL to Nikon adapter from RSB Film in the UK, but they no longer carry it as an item. I was using a Nikon 80-400mm, Sigma 400mm APO Macro, and an old Tokina 80-200 with the XL1, and I was very satisfied with the results. With the XL H1, I have used the same lenses with mixed results. The Nikon 80-400mm falls off at about 380mm, the Sigma 400mm is tack sharp, and the Tokina is also very sharp. I am currently using the Tokina 80-200mm as my work horse lens, and I have coupled a Nikon TC14A (1.4x) with it, which gives me an effective ~2000mm. This combo has worked out very well for me, and so far has produced very sharp and crisp video, even after being down converted to standard DV. Attached are a few images that are video frame grabs from a down converted source. All the images were shot using the Tokina 80-200mm coupled with the TC14A, including the macro shot of the fly. For reasons I don't understand, I have had trouble uploading videos on this site. So, if your interested in seeing videos shot with the Tokina combo, go to this site. http://surfbirds.com/video2/index.php Any video with the user name dond, is mine. Most of them are 16:9, but when they are first displayed, they show as squished 4:3, so click the resize button (blue square) in the lower right corner of the viewer to display right aspect ratio. Attached Thumbnails __________________ Don DesJardin

December 31st, 2007, 12:06 AM	#20
Paul V Doherty Regular Crew Join Date: Aug 2006 Location: USA Posts: 64	Daniel, I'm on a slow satellite uplink for the next 5 months. I'm afraid I can't upload any videos - sorry :( But I CAN vouch for a Nikon-XL adaptor - the results are worth a few hundred dollars for a quality steel or brass adaptor. I don't recommend plastic adaptors. There is no gain in DOF with a Nikon-XL adaptor. You will still get the same DOF at the same focal length as the stock 20x Canon XL lens

January 5th, 2008, 03:24 AM	#22
Michael Sweeney Regular Crew Join Date: Jan 2006 Posts: 97	so what is the real point of this adapter? seems that it would work mostly for wildlife videos because of the huge magnification and such. i was very interested at first because i am looking for something such as the redrock m2 to use slr lens.

January 5th, 2008, 06:33 AM	#23
John Welsh Regular Crew Join Date: Aug 2007 Location: Los Angeles, CA & Cologne, GER Posts: 47	7.2x someone knows what is the multiplyer on 35mm adapters?
