Craig Bellaire · December 29th, 2008, 06:55 PM

just wondered if anyone had thoughts on this camera as a 720P CAPTURE WITH A LAPTOP...

GVI Security SNC-M300 3 Mega Pixel MPEG-4 and JPEG Motion Streaming Color Camera at Markertek.com

The SNC-M300 is a high resolution color network camera that comes equipped with a 3 mega pixel CMOS chip that is capable of progressive QXGA (Quad eExtended Graphics Array) scanning. The camera has a maximum resolution of 2048 x 1536 and comes equipped with a SD card slot for on-alarm event recording retrievable over the network.

Dual Coding & Dual Streaming
With dual-encoding capability, the GV-SNC-M300 can generate and transfer both MJPEG and MPEG4 images simultaneously (PAL 25fps). This dual encoding and streaming capability is useful for transferring MPEG4 images over limited network bandwidth, while also storing high resolution MJPEG Images to the Nertwork Recording Software or NVR device.

The SNC-M300 uses an onboard embedded Linux OS with standard network protocols such as TCP, UDP and FTP among others. The SNC-M300 streams its video output in TCP and UDP (Unicast and Multicast) with MPEG4, MJPEG and G.711 compression. The camera connects to the network by way of a 10/100 Base-T Ethernet connection. The video quality from the camera is available at Very High, High, Normal, Low, and Very Low settings. It supports SAMSUNG DDNS and public DDNS servers. Images are viewable by way of a web browser (IE 6.0 or higher), or with Samsung's Net-i software.

The SNC-M300 has built-in motion detection that can be set at high, medium and low sensitivity. On an alarm event the camera can be set to send an image by FTP, e-mail and record.

The SNC-M300 defends your network integrity by coming equipped with three access levels, administrator, operator and user. The camera supports two way audio and has various time settings, such as NTP Time Sync, Time Zone, and Daylight Savings time setup.

SD Memory Card
User can select important images to be recorded to the SD memory card such as: Alarm Events, Motion Detection or Time Scheduled Events. Using the WebViewer or asd;lkjkkkksoftware, you can remotely access the images from the SD card installed in the SNC-M300. It is compatible with SD and SDHC standard and can support up to 16GB capacity of SDHC memory.

Features
1/2 Inch 3 Mega Pixel Micron CMOS
1.3M / 2M / 3M Pixel HD/Full HD resolution
Dual Codec providing simultaneous MPEG4 & MJPEG
Local storage like 1CH DVR
SD/SDHC memory slot for local storage
Built-in Motion Detection
Pre & Post Alarm Image Buffer
2 Alarm Inputs and 2 Alarm Outputs
DC12V / AC24V / PoE
DDNS Support
Power Over Ethernet (PoE) Support
Bi-Directional Audio Support
C/CS 1/2 Inch Lens Mount
Specifications
Camera Scanning System: Progressive QXGA
Device 3 Mega Pixel CMOS
Size 1/2"
Resolution 2048 x 1536, 1600 x 1200, 1280 x 1024 MJPEG / 640 x 480 MPEG
Minimum Scene Illumination: 2 Lux
Dynamic Range: 50db
Lens: 1/2" CS/C (Adaptor) Manual Iris (not included)
OS Environment Network Board OS Embedded Linux
Client Viewer OS Windows XP, VISTA
Client S/W 1Ch Web Browser Viewer (Default), NET-I CMS S/W (Ver.2.5)
Web browser: Internet Explorer 6.0 higher
Compression: MPEG4 , MJPEG, G.711 Audio & Video Codec
Network Hardware
Flash memory 16MB; SDRAM 128M byte
Ethernet 10/100BASE-T
Network Protocol
TCP, UDP, NTP, HTTP, DHCP, PPPoE
Streaming: TCP, UDP (Unicast, Multicast)
DDNS Supports Samsung DDNS and Public DDNS servers
Resolution
3 Mega 2048 x 1536
2 Mega 1600 x 1200
1.3 Mega 1280 x 1024
VGA (MPEG) 640 x 480
Frame Rate: 25, 19, 13, 12, 10, 6, 3, 1 ips
Video Quality: Very High, High, Normal, Low, Very Low
Motion Detection Sensitivity: High, Medium, Low
Audio: ADPCM, G.711 2-Way
Connection Users: Max 10 Users at Unicast Mode
Alarm Event
Input: Image transfer FTP, E-mail Notification
Motion Detection: Image transfer: FTP, E-mail Notification
Schedule: Image Transfer: FTP, E-Mail / Recording: SD Card
IP Installer IP Address Setup Assistant IP Installation function; (XP, Vista support): Auto detects
Software Upgrade: Firmware upgrade by web browser
Access Level Login Access Level Administrator, Operator, User
Time Setting NTP Time Sync, Time Zone, Day light Saving Setup
Language: Multiple Language GUI Support
SDK
HTTP API CGI Commands: Provides functionality to control cameras and set/retrieve internal parameter values
Windows API Windows API for viewing data streams from network camera
I/O Sockets: Power (2-Pin Term), RJ-45, SD Card Slot, Terminal 6Pin( Alarm In 2Pin, Alarm Out 2Pin, GND)
Environmental Conditions: Operating
Temperature 14§ ~ 122§ F (-10§ ~ 50§ C)
Humidity 20% ~ 85% RH
Power Requirement AC24V (60/50Hz) / DC12V / PoE
LED Indicator: 3ea
Physical Specification Dimensions (WxHxD) 3.26 x 2.39 x 5.78 in
Weight 0.93 lb
Body Color: Silver

Oscar Spierenburg · December 29th, 2008, 07:13 PM

You'd probably be interested in the Elphel project. We are filming 1920 x 1080 pixels (from a 5mpixel chip) to an onboard hard disk right now.
It's an ever continuing project because the founder of Elphel, Andrey Filippov, is devoted to 'open source' and 'open' projects.
Take a look at our thread.

Craig Bellaire · December 30th, 2008, 07:50 AM

that sounds great and I'll look again at the thread BUT that didn't give me any thoughts on this camera... Thanks for the reply...

Sebastian Pichelhofer · December 31st, 2008, 12:19 PM

It looks like an interesting device, here are a few thoughts:

What is Video Quality: Very High?

Frame Rate: 25, 19, 13, 12, 10, 6, 3,
Why not 24?

Resolution: 3 Mega 2048 x 1536
Ok so it's a 4:3 Sensor, but can it also do 16:9 windowing?

There is very little info about how the internal camera parameters like exposure time, white balance, etc are handled.

As Oscar mentioned, this camera is not as powerful as an Elphel at around the same price level.

Craig Bellaire · December 31st, 2008, 06:08 PM

just what I needed to know... thanks so much...
